TECHNICAL DATA
Heating Area	L 200 * W 150 mm
Worktable Size	L 128 * W 128 mm
Workpiece Height	250mm
Workpiece Length	OK
Workpiece Diameter	Φ63 mm
Stamping Pressure	800kgf
Stamping Temperature Range	Room Temperature-280℃
Metallic Foil Width	150mm
Printing Speed	800pcs/hr
Air Consumption	48L/min
Air Pressure	4-7 bar
Vertical Stroke	50 mm
Power Supply	220v/110V 50/60HZ
Heating Wattage	2000W
Machine Dimension	L 650 * W 738 * H 1579mm
Package Dimension	L 870 * W 830 * H 1800 mm
Net Weight	184 kgs
Gross Weight	239 kgs

1. Controlled by Microcomputer.
2. Stamping pressure, temperature, speed can be adjusted.
3. Worktable can be manually move back and forth and rotate adjustment.
4. Automatic foil feeder can be adjusted.
5. Adjustable stamping height
6. Removable shuttle for flat stamping machine
7. Using lubricating device to make shuttle more stable during stamping process. (Option)
