Technical parameter
TECHNICAL DATA |
|
No. of Colors | 1 |
Ink Cup Size | Option 1: Φ70 mmPlate Size: 100*214 mmOption 2: Φ90 mmPlate Size: 100*234 mm |
Plate Size | L 100 * W 75,100 mm |
Worktable Size | L 115 * W 200 mm |
Workpiece Height | 150 |
Workpiece Length | 100 |
Workpiece Diameter | Φ90 mm |
Printing Area | L 80 * W 80 mm |
Printing Speed | 2000pcs/hr |
Air Consumption | 130L/min |
Air Pressure | 4-6 bar |
Vertical Stroke | 80mm |
Horizontal Stroke | 150mm |
Up/Down Worktable |
|
Power Supply | 220v/110V 50/60HZ 50W |
Machine Dimension | L 650 * W 400 * H 1296mm |
Package Dimension | L 800 * W 560 * H 1380 mm |
Net Weight | 89 kgs |
Gross Weight | 112 kgs |
Functional characteristics
1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Two printing heads and two ink trays.
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly
7. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
8. Ink roller is easy to assemble and disassemble for easy cleaning.
