TECHNICAL DATA
Rubber Roller Size	L 140mm *Φ102 mm
Workpiece Height	120 mm
Workpiece Length	150mm
Workpiece Diameter	Φ120 mm
Stamping Pressure	-
Stamping Temperature Range	Room Temperature-280℃
Metallic Foil Width	130mm
Printing Speed	900pcs/hr
Air Consumption	78L/min
Air Pressure	5-8 bar
Vertical Stroke	100 mm
Power Supply	220v/110V 50/60HZ
Heating Wattage	1200W
Machine Dimension	L 589 * W 906 * H 1955mm
Package Dimension	L 1100 * W 750 * H 1950 mm
Net Weight	227 kgs
Gross Weight	287 kgs

1. Controlled by Microcomputer.
2. The roller doesn't create a bubble on the material surface.
3. Installed with a photoelectric sensor.
4. Adjustable transferring time for thermal transfer film.
5. Stamping pressure, temperature, and speed can be adjusted.
6. Equipped with four-digit auto counter.
7. Worktable movement can be adjusted.
8. Adjustable printing height.
9. Adjustable printing head.
10. Automatic thermal transfer film feeder can be adjusted.
