TECHNICAL DATA
Rubber Roller Size	L 200mm *Φ100 mm
Workpiece Height
Workpiece Length	200mm
Workpiece Diameter	Φ150 mm
Stamping Pressure	-
Stamping Temperature Range	Room Temperature-280℃
Metallic Foil Width	250mm
Printing Speed	800pcs/hr
Air Consumption
Air Pressure
Vertical Stroke
Power Supply	220v/110V 50/60HZ
Heating Wattage	2500W
Machine Dimension	L 550 * W 1355 * H 1798mm
Package Dimension	L 810 * W 1300 * H 1950 mm
Net Weight	332 kgs
Gross Weight	412 kgs

1. Stamping pressure, temperature, speed can be adjusted.
2. Worktable can be manually move back and forth and rotate adjustment.
3. Automatic thermal transfer film feeder can be adjusted.
4. Adjustable transferring time for thermal transfer film.
5. Adjustable printing height.
6. Using lubricating device to make shuttle more stable during stamping process.
7. Advanced safety features.
