TECHNICAL DATA
No. of Colors	1
Plate Size	L 100 * W 75/100/150mm
Worktable Size	L 100 * W 220 mm
Workpiece Height	100mm
Workpiece Diameter	-
Printing Area	L 70 * W 70 mm
Printing Speed	1800pcs/hr
Air Consumption	52L/min
Air Pressure	4-6 bar
Vertical Stroke	50 mm
Horizontal Stroke	125 mm
Up/Down Worktable	100mm
Power Supply	220v/110V 50/60HZ 40W
Machine Dimension	L 580 * W 500 * H 1241mm
Package Dimension	L 780 * W 560 * H 1270 mm
Net Weight	55 kgs
Gross Weight	78 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Ink roller is easy to assemble and disassemble for easy cleaning.
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly.
7. It applies ink twice while printing once, in order to obtain clear color retention.
8. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
