Technical parameter
TECHNICAL DATA |
|
No. of Colors | 1 |
Plate Size | L 100 * W 234 mm |
Worktable Size | L 140 * W 270 mm |
Workpiece Height | 150mm |
Workpiece Length | 100mm |
Workpiece Diameter | Φ90 |
Printing Area | L 80 * W 80 mm |
Printing Speed | 1200pcs/hr |
Air Consumption | 52L/min |
Air Pressure | 4-6 bar |
Vertical Stroke | 80 mm |
Horizontal Stroke | 125 mm |
Left and right belt stroke | 100 mm |
Up/Down Worktable | 150mm |
Power Supply | 220v/110V 50/60HZ 50W |
Machine Dimension | L 580 * W 612 * H 1241mm |
Package Dimension | L 780 * W 740 * H 1270 mm |
Net Weight | 62.5 kgs |
Gross Weight | 87.5 kgs |
Functional characteristics
1.microcomputer control of the function of the operation, the operation is simple and convenient.
2.a variety of function settings, suitable for different printing requirements.
3.built-in four-digit automatic counter.
4.the machine architecture uses high quality aluminum alloy, light and strong.
5.independent plastic head up and down stroke and speed adjustment
6.using a closed type ink cartridge ink, environmental protection and save ink, ink utilization up to 94%.
7.It can be printed twice with ink sticking to obtain larger printing ink.
8.automatic cleaning plastic head to ensure the printing quality
9.automatic cleaning plastic head frequency can be set according to the actual situation.
