TECHNICAL DATA
No. of Colors	2
Ink Cup Size	Option Φ70,Φ90
Plate Size	L 100 * W 100 mm
Worktable Size	L 128 * W 140 mm
Workpiece Height	100mm
Workpiece Length	70mm
Workpiece Diameter	-
Printing Area	L 60 * W 60 mm
Printing Speed	1300pcs/hr
Air Consumption	100L/min
Air Pressure	4-6 bar
Vertical Stroke	50 mm
Horizontal Stroke	125 mm
Up/Down Worktable	150mm
Power Supply	220v/110V 50/60HZ 40W
Machine Dimension	L 580 * W 612 * H 1241mm
Package Dimension	L 780 * W 740 * H 1270 mm
Net Weight	62.5 kgs
Gross Weight	87.5 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Two printing heads and two ink trays.
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly.
7. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
8. Ink roller is easy to assemble and disassemble for easy cleaning.
