| TECHNICAL DATA | |
| Maximum Frame Size | L 780 * W 300 mm |
| Minimum Frame Size | L 350 * W 200 mm |
| Workpiece Height | 320mm |
| Workpiece Length | 280mm |
| Workpiece Diameter | Φ185 mm |
| Workpiece Arc | 320mm |
| Workpiece Taper | ±7-15 degree |
| Printing Area | L 580 * W 300 mm |
| Printing Speed | 900pcs/hr |
| Air Consumption | 54L/min |
| Air Pressure | 4-6 bar |
| Vertical Stroke | 100mm |
| Horizontal Stroke | 600mm |
| Up/Down Worktable | 150mm |
| Power Supply | 220v/110V 50/60HZ |
| Machine Dimension | L 600 * W 1050 * H 1375mm |
| Package Dimension | L 1200 * W 1200 * H 1360 mm |
| Net Weight | 154 kgs |
| Gross Weight | 204 kgs |
