TECHNICAL DATA
No. of Colors	2
Plate Size	Option, Φ 70,Φ 90
Plate Size	L 100 * W 75,100 mm
Worktable Size	L 128 * W 140 mm
Workpiece Height	150 mm
Workpiece Length	100mm
Workpiece Diameter	Φ 90mm
Printing Area	L 80 * W 80 mm
Printing Speed	1100pcs/hr
Air Consumption	90L/min
Air Pressure	4-6 bar
Vertical Stroke	80 mm
Horizontal Stroke	125 mm
Up/Down Worktable	150 mm
Power Supply	220v/110V 50/60HZ 50W
Machine Dimension	L 650 * W 585 * H 1296 mm
Package Dimension	L 800 * W 740 * H 1380 mm
Net Weight	74.5 kgs
Gross Weight	99.5 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Two printing heads and two ink trays.
5. Adjustable printing speed.
6. Vertical stroke and speed can be adjusted independently.
7. Auto balanced blade, scraping cleanly.
8. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
9. Automatic blowing dry function.
10.Ink roller is easy to assemble and disassemble for easy cleaning.
