No. of Colors	1
Ink Cup Size	< align="center">Option 1: Φ70 mm Plate Size: 100*314 mm Option 2: Φ90mm Plate Size: 100*234 mm
Plate Size	L150 * W 75, 100,150,200,250,300 mm
Worktable Size	L140 * W 280 mm
Workpiece Height	230 mm
Workpiece Length	150 mm
Workpiece Diameter	Φ90 mm
Printing Area	L 130 * W 80 mm
Printing Speed	1300pcs/hr
Air Consumption	52L/min
Air Pressure	4-6 bar
Vertical Stroke	80 mm
Horizontal Stroke	200mm
Up/Down Worktable	200 mm
Power Supply	220v/110V 50/60HZ
Machine Dimension	L 849 * W 400 * H 1350 mm
Package Dimension	L 1000 * W 520 * H 1300 mm
Net Weight	76.5kgs
Gross Weight	100.5 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Ink roller is easy to assemble and disassemble for easy cleaning.
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly
7. It applies ink twice while printing once, in order to obtain clear color retention.
8. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
