TECHNICAL DATA
No. of Colors	1
Plate Size	L 214 * W 100 mm
Worktable Size	L 115 * W 270 mm
Workpiece Height	150 mm
Workpiece Length	100 mm
Workpiece Diameter	Φ 90 mm
Printing Area	L 80 * W 80 mm
Printing Speed	1200pcs/hr
Air Consumption	52L/min
Air Pressure	4-6 bar
Vertical Stroke	80 mm
Horizontal Stroke	125 mm
Up/Down Worktable	150 mm
Power Supply	220v/110V 50/60HZ 50W
Machine Dimension	L 650 * W 440 * H 1299 mm
Package Dimension	L 800 * W 560 * H 1380 mm
Net Weight	75 kgs
Gross Weight	100 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Ink roller is easy to assemble and disassemble for easy cleaning.
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly.
7. It applies ink twice while printing once, in order to obtain clear color retention.
8. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
