TECHNICAL DATA
No. of Colors	1
Plate Size	L 100 * W 234 mm
Worktable Size	L 140 * W 270 mm
Workpiece Height	150 mm
Workpiece Length	100 mm
Workpiece Diameter	Φ 90 mm
Printing Area	L 80 * W 80 mm
Printing Speed	1200pcs/hr
Air Consumption	52L/min
Air Pressure	4-6 bar
Vertical Stroke	80 mm
Horizontal Stroke	125 mm
Steel plate before and after stroke	100 mm
Up/Down Worktable	150 mm
Power Supply	220v/110V 50/60HZ 50W
Machine Dimension	L 650 * W 400 * H 1299 mm
Package Dimension	L 800 * W 560 * H 1380 mm
Net Weight	75 kgs
Gross Weight	100 kgs

1. The microcomputer controls the operation of each function, and the operation is simple and convenient.
2. Various function settings, suitable for different printing requirements.
3. Built-in four-digit automatic counter.
4. The machine structure uses high quality aluminum alloy, light and strong.
5. Independent rubber head up and down stroke and speed adjustment
6. The use of enclosed ink cartridges to ink, environmental protection and save ink, ink utilization up to 94%.
7. It is possible to pad ink twice for a larger printing ink.
8. Automatic cleaning plastic head to ensure printing quality
9. Automatic cleaning plastic head frequency can be set according to the actual situation.
