TECHNICAL DATA
No. of Colors	1
Ink Cup Size	-
Plate Size	L 100 * W 100,150 mm
Worktable Size	L 130 * W 140 mm
Workpiece Height	-
Workpiece Length	-
Workpiece Diameter	Φ 40 mm
Printing Area	L 80 * W 80 mm L 80 * W 130 mm
Printing Speed	1200pcs/hr
Air Consumption	130L/min
Air Pressure	4-6 bar
Vertical Stroke	80 mm
Horizontal Stroke	125 mm
Up/Down Worktable	150 mm
Power Supply	220v/110V 50/60HZ
Machine Dimension	L 650 * W 585 * H 1296 mm
Package Dimension	L 800 * W 740 * H 1380 mm
Net Weight	74.5 kgs
Gross Weight	99.5 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Light weight and made with high-quality aluminum material components.
4. Two printing heads and two ink trays. (Option)
5. Vertical stroke and speed can be adjusted independently.
6. Auto balanced blade, scraping cleanly
7. Cannot leave blank lines before and after loading the machine to prevent pauses when the ink is dried.
8. Ink roller is easy to assemble and disassemble for easy cleaning.
