Maximum Frame Size	L 720 * W 350 mm
Minimum Frame Size	L 280 * W 200 mm
working desk size	L 600 * W 400 mm
Workpiece Height	150mm
Workpiece Length	300mm
Table before and after the trip	250mm
Printing Area	L 400 * W 400 mm
Printing Speed	1000pcs/hr
Air Consumption	183L/min
Air Pressure	4-6 bar
Vertical Stroke	150mm
Horizontal Stroke	450mm
Up/Down Worktable	/
Power Supply	220v/110V 50/60HZ
Machine Dimension	L 1000 * W 650 * H 1550mm
Package Dimension	L 1100 * W 700 * H 1600 mm
Net Weight	200 kgs
Gross Weight	325 kgs

1. Controlled by Microcomputer.
2. Equipped with four-digit auto counter.
3. Round face and conical printing function.
4. Automatic scraping.
5. Adjustable printing stroke and printing speed.
6. Auto balance blade with the equalized printing pressure.
7. Workbench and frame holder can be adjust back and forth, left and right, up and down.
8. The blade can be independently lifted for replacement and cleaning.
